Due to the container volumes from 10 to 16m³ and the width of 2m, the MULTIPRESS 1.0 suits to narrow surrounding areas. The press technology contains all advantages of the big brother and characterizes due to its efficiency, high compaction ratio and durability.
|Length (without rear hook)||4960||5460||5960||6460|
|Length (with rear hook)||5200||5700||6200||6700|
|Width x Height||1950 x 2440||1950 x 2440||1950 x 2440||1950 x 2440|
|Height of opening||1400 mm||1400 mm||1400 mm||1400 mm|
|Volume/stroke||1 m³||1 m³||1 m³||1 m³|
|Feed opening WxL||1450 x 1000 mm||1450 x 1000 mm||1450 x 1000 mm||1450 x 1000 mm|
|Filling opening W x L||1450 x 1580 mm||1450 x 1580 mm||1450 x 1580 mm||1450 x 1580 mm|
|Compression force||300 kN||300 kN||300 kN||300 kN|
|Time taken for compression action||24 s||24 s||24 s||24 s|
|Motor rating||5,5 kW||5,5 kW||5,5 kW||5,5 kW|
|Slow fuse||16 A||16 A||16 A||16 A|
|Unloaded weight||3390 kg||3550 kg||3720 kg||3880 kg|
|Cone||3 x 100mm||3 x 100 mm||3 x 100 mm||3 x 100 mm|
Update your machines to the latest Pöttinger technology! With Falconic you get the perfect overview of all essential machine functions. Thereby you optimize the use of your press container and reduce costs.
Falconic saves logistic costs by
Site specific configuration of the press in the Webinterface
Maximum container load
Pre-full and full announcement with container position by Email/ SMS
Detection of filling level 50 – 100% by analysis of the pressure curve
Falconic saves scheduling costs
Perfect planning of collecting and emptying the machine
GPS tracking and visualisation in the Webinterface
Overview of containerpool
Falconic saves maintenance costs
Automatic detection and adaptation of the rotating direction
Working time monitoring
Everything from a single source: Pöttingeroffers a complete System - modern press technique, control module plus SIM-card, online data processing program and services
Improved capacity by the newly developped press geometry raises not only the competetiveness of our clients but also protects the environment. A reduction of transport costs up to 20% in comparison to our competitors can be achieved.
High quality piston guiding: Special bearing-mounted, wear-resistant synthetic slide rails (guidance right/ left/ bottom) scan the press floor and walls ensuring a long service life and trouble-free operation of the ram. The press chamber is kept clean as an aditional benefit.
Convcave press plate (of highly wear-resistant steel): Cooperation between the sloping press floor and the concave press plate increases the level of compaction up to 20%.
Inclined press floor: Also qualifies the press container for use with wet waste. Reduced susceptibility to repairs in the press chamber as liquids remain in the container. The technology area is clean.
Whether the machine is equipped with a standard hopper, a ramp hopper or higher sidewalls the MP 1.0 Roll-off/ skip machine with its hopper versions is prepared for all deployment possibilites.
Dumping system: Preparation as a standard - no welding needed for retrofitting. Additionally to the DIN arms a hydraulic comb lift can be mounted for different bin sizes according to DIN 840/1, 840/2 und 840/3
The waste press is delivered with a low noise gear pump as a standard. The machine running idle has less than 59 dBA.
Powder coating with primer and top coat.
Pöttinger coating line technology incorporates poweder coating with primer and top coat. This ist the most environmentally friendly painting method because the manufacture is carried out without any solvents.
This process involves the following steps: First the surface is cleaned and sandblasted. A surface quality of up to RA 2 1/2 can be achieved. In the second step the primer and the top coat are applied. The minimum paint thickness is 120µ. The powder coating finish needs to be baked at between 180°C and 200°C to achieve the best possible quality. Here, the components obtain their final gloss finish. The result is a tough, elastic and impact-resistance surface finish.
Freedom of Design: CamoDesign ist the freely configurable promotional textile which encases our machines and gives a clean apperance - over the entire service life. A clean environment manifests itself not only in the operation of the machine but also in appearance.
Due to its new maintenance platform which is covered with a non-slip material a safe service of the electric and hydraulic system is guaranteed.
The MP 1.0 roll-off container can be delivered also as garage modell. With a height of 2000 mm it is able to achieve much even in narrow surroundings.
Mixed waste and waste with high rate of liquids can be ideally compacted. The sloping press floor and the 300 mm step between press and container floor (trashholder) grant a clean technology area.
